Table working area (L×W): 1600mm × 320mm
Longitudinal travel (manual/power): 900mm / 880mm
Cross travel (manual/power): 315mm / 300mm
Vertical travel (manual/power): 385mm / 365mm
Spindle taper: ISO 50 (7:24)
Spindle speed range: 30 – 1500 rpm (18 steps)
Spindle motor power: 7.5 kW
Overall dimensions (L×W×H): 2272mm × 1770mm × 2094mm
Machine weight: approx. 3200 kg
Machine Name | Type | Description
The Beijing No.1 Machine Tool Plant XA6132 universal knee-type milling machine is a versatile and rugged mill designed for general machining workshops, tool rooms, and maintenance facilities. The universal table can be swivelled up to ±45°, allowing efficient helical, spiral, and angular milling operations on workpieces such as gears, splined shafts, twist drills, cams, and spiral grooves. With its rigid construction and stable spindle performance, this machine handles both ferrous and non-ferrous materials with consistent accuracy.
Each unit undergoes strict in-process and final inspections to ensure reliable performance and long-term durability. We prioritize quick dispatch from our centralized warehouse, supported by a responsive after-sales team. The XA6132 delivers the flexibility, dependability, and efficiency that busy shops require for everyday milling tasks and complex angle work.
