Baoji CS6240B Gap Bed Lathe *1500mm
Baoji CS6240B is a versatile gap bed lathe offering a large swing in the gap for oversized workpieces. Ideal for general machining, repair shops, and job shops needing to handle both long shafts and large-diameter discs. Dependable performance, robust construction, and fast delivery.
$ Click to Get Price
Machine Parameters
Swing over bed: 400 mm
Swing over saddle: 220 mm
Swing in gap: 630 mm
Gap width: 210 mm
Distance between centers: 750/1000/1500/2000/3000 mm
Max. turning length: Configurable
Spindle bore: 52 mm
Spindle speed: 24 steps 9-1600 rpm
Main motor power: 7.5 kW
Bed width: 350 mm
Tailstock taper: MT5#
Net weight: 1850-2900 kg
Voltage: 380V/50Hz (Customizable)
Tool shank size: 25×25 mm
